| 研究 / 潜水 / PAX CAT 与 ROV、HIPAD、HELIDECK | |
| 船舶编号 | 5783 |
| 类别 | 机动船 |
| 建造年份 | 2008 |
| 发货添加日期 | 2022-03-06 |
| 添加者 | Norsk Megling & Auksjon AS |
船舶尺寸
| 总长度 (LOA), 米 | 35 |
| 船舶吃水, 米 | 2.2 |
附加信息
| 主机 | for the «Queen of the Environment» and there are two MAN D2842LE 410, each with an output of 809 kW at 2160 rpm. Servogear has delivered gears of the type HD295 PTIR-HR (PTIL-HFR) 4.21: 1, and rotary propellers of the type 9P820-1002B and rudders of the type Effektror 9R054-HV. The steering machine is of the type Scana Mar-El. Auxiliary motors and generators are supplied by Nogva Motorfabrikk AS and consist of two Nogva Deere with the designation 6068 TFM 50 of 83 kW at 1500 rpm. and two Stamford UCM 274 G with a power each of 83 kW, 230 V, 50 Hz, 104 kVA. Two bow thrusters of the type SB60-80 V80 and the thruster aft have the same designation, and they are supplied by MB Hydrauliikk. At 2100 rpm. is the speed of 21.4 knots with an engine power of 735 kW, and a range of 864 nautical miles. At 2000 rpm. the speed can be 17.5 knots with an engine power of 600 kW, and a range of 970 nautical miles. At 1800 rpm. the speed is 16.4 knots at 540 kW |
| 自走式 | |
| 甲板 | 1 |
| 乘客 | 50 |
